Description
Key Product Features
Under ceiling mounting – no need for suspended ceiling space
Stylish rounded panels with a compact, slim body
Full-function Eco Touch controller with 90+ setting options
7-Day / 24-Hour Programmable Timer
Dual ON/OFF daily schedules with temperature control
High airflow with improved anti-smudge discharge
Inverter technology for energy savings
Quiet operation with reduced sound pressure
Auto restart & low ambient operation
Long refrigerant pipe runs supported
Optional WiFi and IR control, motion sensors, and BMS integration
Technical Specifications
Indoor Unit – FDE140VH
Dimensions (H × W × D): 250 × 1620 × 690 mm
Net Weight: 43 kg
Airflow (H/M/L): 29 / 23 / 18 m³/min
Sound Pressure (H/M/L): 45 / 40 / 36 dB(A)
Outdoor Unit – FDC140VSA-W
Dimensions (H × W × D): 845 × 970 × 370 mm
Net Weight: 78 kg
Sound Pressure (Cooling/Heating): 56 / 58 dB(A)
Performance
UK Cooling Capacity: 12.60 kW
UK Sensible Cooling: 9.50 kW
Cooling Range (Nominal): 5.0 – 14.5 kW
Heating Range (Nominal): 4.0 – 16.5 kW
SEER / EER: 5.76 / 2.69
SCOP / COP: 4.24 / 3.71
Energy Labels: A++ (cooling), A+ (heating)
Electrical
Power Supply: 3 Phase, 380 – 415V, 50Hz
MCB Rating: 20A per phase
Max Running Current: 15 A
Start Current: 5 A
Interconnect Cable: 3+E (1.5 mm²)
Refrigerant & Pipework
Refrigerant Type: R32
Precharged Amount: 3.3 kg (2.228 TCO₂Eq)
Piping Length (Max): 50 m
Vertical Height Difference (Max): 50 m (above) / 15 m (below)
Pipe Size (Liquid / Suction): 3/8 in / 5/8 in
Additional Refrigerant Charge: 54 g/m (after 30 m)
Compatible Accessories
Product No.
Description
RCN-E-E3
IR Remote Control & Receiver Kit (for FDE**VG/F)
LB-E
Motion Sensor (for use with RC-EX3A Controller)
RCE5
Wired Controller
RCEX3A
Eco Touch Controller (included)
RCH-E3
Simplified Controller
PCZ006A043
6 Wire Adaptor
INMBSM-HI001R000
Modbus Interface – 1 Indoor Unit
INKNXM-HI001R000
KNX Interface – 1 Indoor Unit
SC-ADNA-E
Superlink Adaptor
IHWFIM-HI001R000
Intesis Home WiFi Interface (Hard Wired)
AZA16WSCMHI
Airzone Aido WiFi Module
SC-THB-E3
Remote Sensor (8m)
SSA42A024
Elbow for Condensate Drain Kit (1 required)
SSA947089
Grommet for Condensate Drain Kit (4 required)
