Description
Technical Information:
| OUTDOOR | UU24WR U40 | |||
| CompressorAirflow Rate | Type | Nom | m3/min | Twin Rotary58 |
| Cooling | Nom | dBA | 48 | |
| Sound Pressure | Heating | Nom | dBA | 52 |
| Sound Power | Cooling | Max | dBA | 67 |
| Dimensions | W x H x D | mm | 950 x 834 x 330 | |
| Net Weight | kg | 56.1 | ||
| Type | R32 | |||
| Charge | g | 1,600 | ||
| Refrigerant | Additional Charge | (after 7.5m) | g/m | 35 |
| GWP | 675 | |||
| t-CO2 eq | 1.08 | |||
| Cooling | Min ~ Max | °C DB | -15 ~ 48 | |
| Operation Range (Outdoor) | Heating | Min ~ Max | °C WB | -18 ~ 18 |
| Power Supply Power Supply Cable Transmission Cable | Ø / V / HzNo. x mm2 No. x mm2 | 1 / 220-240 / 503C x 2.54C x 0.75 | ||
| Circuit Breaker | A | 25 | ||
| Piping Length Total | Min ~ Max | m | 5 ~ 50 | |
| Piping Elevation Difference | IDU – ODU | Max | m | 30 |
| Liquid | mm (inch) | Ø 9.52 (3/8) | ||
| Piping Connection | Gas | mm (inch) | Ø 15.88 (5/8) |
| INDOOR | CM24R N10 | |||
| Capacity | Cooling Min / Nom / Max | kW | 2.8 / 6.8 / 7.8 | |
| Heating | Min / Nom / Max | kW | 3.2 / 7.5 / 8.3 | |
| Low Temperature Capacity | Heating -7°C Max | kW | 7.2 | |
| Power Input (Set) | Cooling Nom | kW | 2.03 | |
| Heating | Nom | kW | 2.20 | |
| Power Input (Indoor) | Min / Max (ESP 2.5mmAq) | W | 50 / 90 | |
| Min / Max (ESP 8.0mmAq) | W | 100 / 180 | ||
| Running Current | Cooling / Heating Nom | A | 9.0 / 9.8 | |
| Power Supply | Ø / V / Hz | 1 / 220-240 / 50 | ||
| EER | 3.35 | |||
| COP | 3.40 | |||
| SEER | 6.81 | |||
| SCOP | 4.01 | |||
| Pdesign (@-10°C) | kW | 5.4 | ||
| Seasonal Energy Label | Cooling / Heating (A++ to E Scale) | A++ / A+ | ||
| Annual Energy Consumption | Cooling / Heating | kWh | 350 / 1,890 | |
| Piping Connection | Liquid | mm (inch) | Ø 9.52 (3/8) | |
| Gas | mm (inch) | Ø 15.88 (5/8) | ||
| Drain | O.D. / I.D. | mm | 32.0 / 25.0 | |
| Air Flow Rate | High / Medium / Low | m3/min | 18.0 / 16.5 / 14.5 | |
| Sound Pressure | Cooling | High / Medium / Low | dBA | 35 / 34 / 32 |
| Sound Power | Cooling | Max | dBA | 60 |
| Dehumidification Rate | l/h | 2.5 | ||
| Dimensions | Body | W x H x D | mm | 900 x 270 x 700 |
| Net Weight | Body | kg | 26.5 | |
| External Static Pressure | Min ~ Max | mmAq (Pa) | 2.5~15 (25~147) | |
These air conditioning units must be installed by an F-Gas qualified engineer. ( We will ask to view this certificate before the shipment) We can install the unit for you using our F-Gas Certified Engineers.
