Description
Key Product Features:
SEER + SCOP = A+++ on the entire range
No need to clean filters, thanks to the self cleaning filter
Unique combination of humidification, dehumidification, ventilation, air purification and heating & cooling in 1 system
Reddot design award winner 2013
Online controller (optional): control your indoor from any location
with an app, via your local network or internet
First R-32 air-to-air heat pump in the European market
Technical Specification:
| Indoor Units | FTXZ50N | ||
| Capacity | UK Total Cooling | kW | 5.58 |
| UK Sensible Cooling | kW | 3.77 | |
| Nominal Cooling | kW | 5.00 | |
| Nominal Heating | kW | 6.30 | |
| Seasonal Efficiency (EN14825) COOLING | Energy Label | A+++ | |
| Pdesign | kW | 5.00 | |
| SEER | 8.60 | ||
| Annual Energy Consumption | kWh | 203 | |
| Seasonal Efficiency (EN14825) HEATING | Energy Label | A+++ | |
| Pdesign | kW | 5.60 | |
| SCOP | 5.50 | ||
| Annual Energy Consumption | kWh | 1427 | |
| Nominal Efficiency | EER / COP | 4.55 / 4.47 | |
| Energy Label | A / A | ||
| Annual Energy Consumption | kWh | 550 | |
| Air Flow Rate (Cooling) High / Nom / Low / S Low | m3/sec | 0.250 / 0.153 / 0.110 / 0.077 | |
| Dimensions | Height | mm | 295 |
| Width mm | 798 | ||
| Depth mm | 372 | ||
| Weight | kg | 15 | |
| Sound Pressure (Cooling) High / Nom / Low / S Low | dBA | 47 / 38 / 30 / 23 | |
| Sound Power | dBA | 60 | |
| Outdoor Units | RXZ50N | ||
| Dimensions Height x Width x Depth | mm | 693 x 795 x 300 | |
| Weight | kg | 50kg | |
| Electrical Details | Power Supply | 1ph | |
| Running Current | A | 4.80 | |
| Starting Current | A | 6.2 | |
| Max Fuse Size | A | 16 | |
| Interconnection Wiring Core / Cable size | 3+E / 1.5 | ||
| Piping Connections Liquid / Gas | inches (mm) | 1/4 (6.4) / 3/8 (9.5) | |
| Pipework | Maximum Length | m | 10 |
| Maximum Vertical Rise | m | 8 | |
| Precharged to | m | 10 | |
| Holding Charge | kg | 1.34 | |
| Sound Pressure (Cooling) High | dBA | 49 | |
| Sound Power | dBA | 63 | |
| Air Flow Rate High | m3/sec | 0.673 | |
| ECA Eligible | yes |
These air conditioning units must be installed by an F-Gas qualified engineer. ( We will ask to view this certificate before the shipment) We can install the unit for you using our F-Gas Certified Engineers.
